MVT203S

Two-way actuator designed for control applications on two-/four-pipe fan coil units, small air handling units, solar systems, and the control of post-heating and dehumidification coils where small and compact motorized valves are required. Three-point or ON/OFF control, force 300 N, stroke 9 mm, IP43 protection rating, power supply 230 Vac 50/60 Hz, power consumption 16.2 VA. The MVT model allows for easy installation on valves with an M30x1.5 threaded ring. It can be mounted directly on CONTROLLI valve bodies models VMBT, VSBT, VX.T and 2TGA.B.
