MDL66PA6

Industrial servo motor used in civil and industrial control systems for operating dampers and other devices that require the control of an angular position within a maximum angle of 160° (e.g., to modulate the flame of gas or oil burners), two or three-position control, timing 60…107 s, torque 30 Nm, power supply 110 Vac 50/60 Hz, double shaft output, IP55 protection rating, internal shaft release mechanism to allow free rotation of the shaft in both directions, external graduated position indicator splined to the shaft outputs. Complete with 1 KOhm potentiometer.
