MDL62

Industrial servo motor used in civil and industrial control systems, for controlling dampers and other devices that require control of an angular position within a maximum angle of 160° (e.g., to modulate the flame of gas or oil burners), two or three-position control, timing 15-27 s, torque 6 Nm, power supply 110 Vac 50/60 Hz, dual shaft output, IP55 protection rating, internal shaft release mechanism to allow free rotation in both directions, external graduated position indicator coupled to the shaft outputs.
