GPC326.1A

Rotary damper actuator with spring return, torque 4 Nm, running time in normal operation 60 s, running time in power failure 15 s, rotation angle 90°, power supply AC 100...240 V, 2-position control signal, 2 auxiliary microswitches, IP54 protection, manual override with dedicated key, control signal with 2-wire contact, PVC connection cable 0.9 m long, rotation direction dependent on actuator mounting direction, integrated mechanical rotation angle limiter, position indicator, for air dampers up to approximately 0.6 m².
